电源负载开关, AEC-Q100, 高压侧, 2输出, 28 V, 20 A/0.1 ohm输出, SOIC-14
电源开关/驱动器 1：1 N 通道 2.2A PG-DSO-14-40-EP
得捷:
IC PWR SWITCH N-CHAN 1:1 DSO-14
欧时:
Smart High-Side 2-Ch Power Switch SOIC14
立创商城:
BTT61002EKAXUMA1
艾睿:
Current Limit SW 2-IN 2-OUT 8V to 36V 2.6A Automotive 14-Pin DSO EP T/R
安富利:
Power Switch Hi Side 2.6A 14-Pin DSO T/R
Verical:
Current Limit SW 2-IN 2-OUT 8V to 36V 2.6A Automotive 14-Pin DSO EP T/R
Win Source:
IC PWR SWITCH N-CHAN 1:1 DSO-14 / Power Switch/Driver 1:1 N-Channel 2.2A PG-DSO-14-40-EP
输出接口数 2
输入电压DC 28.0 V
输出电流 2.6 A
供电电流 4 mA
针脚数 14
耗散功率 1.8 W
输入电压Min 8 V
输出电流Max 2.2 A
输入数 2
工作温度Max 150 ℃
工作温度Min -40 ℃
耗散功率Max 1800 mW
输入电压 36 V
安装方式 Surface Mount
引脚数 14
封装 PG-DSO-14-40-EP
封装 PG-DSO-14-40-EP
工作温度 -40℃ ~ 150℃ TJ
产品生命周期 Active
包装方式 Tape & Reel TR
制造应用 Replaces electromechanical relays, fuses and discrete circuits, Suitable for resistive, inductive and capacitive loads, Most suitable for loads with highinrush current, such as lamps, Suitable for 24V Trucks and Transportation System
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ECCN代码 EAR99
