低饱和电压型3针调节器;•内置过压保护电路,过流保护电路和热关断电路
电路数量Number of Regulators| 1 \---|--- 输入电压VINVoltage - Input| 10~25V 输出电压VOUTVoltage - Output| 9V 输出电流IoCurrent - Output| 1A 最大压降VDOVoltage - Dropout| 300mV/0.3V 带使能脚EN/CEON/OFF功能With Enable Pin| 无 No 最大耗散功率PdPower dissipation| 1W Description & Applications| Low saturation voltage type 3-pin regulator ;•Built-in overvoltage protection circuit, overcurrent protection circuit and thermal shutdown circuit 描述与应用| 低饱和电压型3针 调节器;•内置过压保护电路,过流保护电路和热关断电路
得捷:
IC REG LINEAR 9V 1A TO252-3
艾睿:
LDO Regulator Pos 9V 1A 3-Pin2+Tab CPT T/R
Chip1Stop:
LDO Regulator Pos 9V 1A 3-Pin2+Tab TO-252 T/R
DeviceMart:
IC REG LDO 9V 1A TO252-3
Win Source:
Linear Voltage Regulator IC Positive Fixed 1 Output 9V 1A TO-252-3
输出接口数 1
输入电压DC 25.0V max
输出电压 9 V
输出电流 1 A
跌落电压 0.3V @500mA
输入电压Max 25 V
输入电压Min 10 V
输出电流Max 1 A
工作温度Max 85 ℃
工作温度Min -40 ℃
耗散功率Max 1000 mW
输入电压 10V ~ 25V
安装方式 Surface Mount
引脚数 3
封装 TO-252-3
封装 TO-252-3
工作温度 -40℃ ~ 85℃
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
