VISHAY BFC237363105 膜电容, MKT373系列, 1 µF, ± 10%, PET聚酯, 630 V
The is a radial potted DC Film Capacitor with polyester film dielectric and metallised electrodes. The MKT373M Mini series automotive grade capacitor has tinned wire leads and mono construction. It assists energy conversion while providing low losses, high efficiency and long life. For general purpose applications of DC-filtering, coupling, bypassing timing and interference suppression on low-voltage circuits.
- .
- UL94V-0 flame-retardant epoxy resin sealed plastic case encapsulation
- .
- Grade 1 long life Performance grade
额定电压DC 630 V
额定电压AC 250 V
绝缘电阻 30.0 GΩ
电容 1 µF
容差 ±10 %
易燃性等级 UL 94 V-0
工作温度Max 105 ℃
工作温度Min -55 ℃
额定电压 630 V
安装方式 Through Hole
引脚数 2
封装 Radial, Box
引脚间距 27.5 mm
长度 31.5 mm
宽度 15 mm
高度 15 mm
脚长度 4.00 mm
封装 Radial, Box
引脚间距 27.5 mm
介质材料 Polyester
工作温度 -55℃ ~ 105℃
包装方式 Each
制造应用 Industrial, Automotive, 通用, Lighting, Consumer Electronics
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC标准 No SVHC
| 型号/品牌 | 代替类型 | 替代型号对比 |
|---|---|---|
BFC237363105 Vishay Semiconductor 威世 | 当前型号 | 当前型号 |
B32524Q8105K000 爱普科斯 | 功能相似 | BFC237363105和B32524Q8105K000的区别 |
