BT138-600

NXP  BT138-600  三端双向可控硅, 600 V, 5 W, 1.5 V, TO-220, 95 A

The from NXp is a planar passivated four quadrant triac in 3 pin SOT78 TO-220AB plastic package. Triac are intended for use in applications requiring high bidirectional transient and blocking voltage capability and high thermal cycling performance. Typical applications include heating and static switching.

.

High blocking voltage capability

.

Less sensitive gate for improved noise immunity

.

Planar passivated for voltage ruggedness and reliability

.

Maximum gate trigger voltage of 1V

.

Maximum holding current is 30mA

.

RMS onstate current is 12A

.

Maximum junction temperature of 125°C

.

Peak gate power of 5W

.

Non repetitive peak on-state current of 95A

.

Repetitive peak off state voltage of 600V
