BCS-108-L-D-PE-BE

SAMTEC BCS-108-L-D-PE-BE Board-To-Board Connector, 2.54mm, 16Contacts, Receptacle, BCS Series, Solder, 2Rows

16 位置 插座，通透式 0.100"（2.54mm） 通孔 镀金

欧时:
.100" 2.54 mm Tiger Claw Pass-through

得捷:
CONN RCPT 16POS 0.1 GOLD PCB

艾睿:
Use this socket strip BCS-108-L-D-PE-BE connector from Samtec when board-to-board interconnects is required. This SKT connector&s;s 16 contacts that are made out of phosphor bronze and plated with gold over nickel. It has a straight body orientation. It has a maximum voltage rating of 475 VAC. It has a socket type gender. This is a 2-row connector. Its pitch is 2.54 mm. This device has a maximum current rating of 4.6 A/contact. In order to ensure parts aren&s;t damaged by bulk packaging, this product comes in tube packaging to add a little more protection by storing the loose parts in an outer tube. BCS-108-L-D-PE-BE is housed in black liquid crystal polymer. This product is 20.32 mm long, 7.44 mm tall and 7.62 mm deep. This connector has an operating temperature of -55 to 125 °C. It uses the solder termination method.

安富利:
Conn Socket Strip SKT 16 POS 2.54mm Solder ST Thru-Hole Tube

Newark:
# SAMTEC  BCS-108-L-D-PE-BE  Board-To-Board Connector, 2.54 mm, 16 Contacts, Receptacle, BCS Series, Solder, 2 Rows
