SAMTEC BDL-107G-F Board-To-Board Connector, 2.54mm, 14Contacts, Header, BDL Series, Through Hole, 2Rows
* Low profile design achieves 3, 89 mm .153" board spacings when mated with SL Series. * Approach the reliability of a permanent connection with the flexibility of a separable connection. * Low Profile Double Row
艾睿:
This unshrouded BDL-107-G-F header connector from Samtec reduces the possibility of accidentally shorting pins when a board is being used. This HDR connector&s;s 14 contacts that are made out of phosphor bronze|brass and plated with gold over nickel. Its pitch is 2.54 mm. It has a straight body orientation. It has a header type gender. This is a 2-row connector. This device has a maximum current rating of 1 A/contact. In order to ensure parts aren&s;t damaged by bulk packaging, this product comes in tube packaging to add a little more protection by storing the loose parts in an outer tube. This product is 17.78 mm long, 5.34 mm tall and 5.08 mm deep. BDL-107-G-F is housed in black nylon. This connector has an operating temperature of -55 to 125 °C. It uses the solder termination method.
安富利:
Conn Unshrouded Header HDR 14 POS 2.54mm Solder ST Thru-Hole Tube
Verical:
Conn Unshrouded Header HDR 14 POS 2.54mm Solder ST Top Entry Thru-Hole Tube
Newark:
# SAMTEC BDL-107-G-F Board-To-Board Connector, 2.54 mm, 14 Contacts, Header, BDL Series, Through Hole, 2 Rows
