BT151S-650R

NXP Semiconductors 闸流晶体管 - NXP Semiconductors 闸流晶体管是一种固态半导体设备，具有四层交替的 N 型和 P 型材料。 它们充当双稳态开关，当它们的栅极接收到电流触发时发挥作用，并在处于正向偏压时继续发挥作用。 闸流晶体管与硅控整流器 SCR 同义。

General description

Passivated thyristors in a SOT428 plastic package.

Features

High thermal cycling performance

Surface-mounted package

High bidirectional blocking voltage capability

Applications

Motor control

Static switching

Ignition circuits

Protection circuits

Quick reference data

VDRM≤500 V BT151S-500L/R

ITSM≤120 A t = 10 ms

VRRM≤500 V BT151S-500L/R

ITRMS≤12 A

VDRM≤650 V BT151S-650L/R

ITAV≤7.5 A

VRRM≤650 V BT151S-650L/R

IGT≤5 mA BT151S series L

VDRM≤800 V BT151S-800R

IGT≤15 mA BT151S series R

VRRM≤800 V BT151S-800R
