B3B-XH-ALFSN

JST JAPAN SOLDERLESS TERMINALS  B3B-XH-A LFSN  线至板连接器, 垂直, XH系列, 3 触点, 针座, 2.5 mm, 通孔安装, 1 排

XH 针座

这些 XH 系列盒型有罩管座提供顶部接入和侧面装入配置。 这些 XH 系列盒型有罩管座的晶片材料为 PA66，等级为 UL 94V-0，颜色为本色（白色）。 支柱采用镀锡黄铜，用于这些 XH 系列盒型有罩管座。

有关匹配的 XH 系列插头外壳，请参见典型库存号 820-1611。

产品规格

---

材料，表面处理

    支柱：黄铜，铜二道底漆，镀锡合金

    基座：尼龙 66 UL94V-0，自然（白色）

得捷:
CONN HEADER VERT 3POS 2.5MM

欧时:
JST PCB 针座 XH 系列 3路 2.5mm节距 1排 直向 B3B-XH-ALFSN, 焊接端接, 3A, 通孔

立创商城:
XH 2.5mm 1x3P

艾睿:
Mounting this shrouded B3B-XH-A LFSN header connector from JST Corporation to your printed circuit board can help you support multiple physical configuration options. This HDR connector&s;s 3 contacts that are made out of brass and plated with tin-lead over copper. It has a maximum voltage rating of 250 VDC|250VAC. This is a 1-row connector. It has a header type gender. Its pitch is 2.5 mm. It has a straight body orientation. This device has a maximum current rating of 3 A. This product is 9.9 mm long, 7 mm tall and 5.75 mm deep. B3B-XH-A LFSN is housed in white polyamide 6/6. This connector has an operating temperature of -25 to 85 °C. It uses the solder termination method.

富昌:
XH Series 3 Position 2.5 mm Pitch Through Hole Crimp Top Entry Shrouded Header

Chip1Stop:
Conn Shrouded Header HDR 3 POS 2.5mm Solder ST Thru-Hole Box

Verical:
Conn Shrouded Header HDR 3 POS 2.5mm Solder ST Top Entry Thru-Hole Box

Newark:
Wire-To-Board Connector, 2.5 mm, 3 Contacts, Header, XH Series, Through Hole, 1 Rows

CDI:
ShroudedHdr, ThruHole, Top Entry, 3Circuit, 2.5mmPitch
