智能电源负载开关, 高压侧, AEC-Q100, 1输出, 28V, 86A, 0.01欧姆, HSOIC-14
电源开关/驱动器 1:1 N 通道 9A PG-DSO-14-47-EP
得捷:
IC PWR SWITCH N-CHAN 1:1 DSO-14
立创商城:
BTT60101EKBXUMA1
艾睿:
Current Limit SW 1-IN 1-OUT 8V to 36V 9A Automotive 14-Pin DSO EP T/R
安富利:
IC PWR SW HI-SIDE 1CH 14DSO
Verical:
Current Limit SW 1-IN 1-OUT 8V to 36V 9A Automotive 14-Pin DSO EP T/R
Win Source:
IC PWR SWITCH N-CHAN 1:1 DSO-14 / Power Switch/Driver 1:1 N-Channel 9A PG-DSO-14-47-EP
输出接口数 1
针脚数 14
耗散功率 1.6 W
输入电压Min 8 V
输出电流Max 9 A
输入数 1
工作温度Max 150 ℃
工作温度Min -40 ℃
耗散功率Max 1600 mW
输入电压 36 V
安装方式 Surface Mount
引脚数 14
封装 PG-DSO-14-47-EP
封装 PG-DSO-14-47-EP
工作温度 -40℃ ~ 150℃ TJ
产品生命周期 Active
包装方式 Tape & Reel TR
制造应用 Replaces electromechanical relays, fuses and discrete circuits, Suitable for 24V trucks + trailer and transportation systems, Suitable for resistive, inductive and capacitive loads, Most suitable for loads with high inrush current, such as lamps
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ECCN代码 EAR99
