BD04AV

DIL 开关适合波焊 适用于浸洗 “开”标签清楚地指明开/关位置 扩展执行器 非切换额定值：100mA @ 50V 直流 触点电阻：50mΩ ### 注除非另有说明，否则这些开关不适于浸泡清洗。### DIL 直通板

直角 DIL

适合波焊

适用于浸洗

“开”标签清楚地指明开/关位置

扩展执行器

非切换额定值：100mA @ 50V 直流

触点电阻：50mΩ

### 注

除非另有说明，否则这些开关不适于浸泡清洗。

得捷:
SWITCH SLIDE DIP SPST 100MA 5V

立创商城:
BD04AV

欧时:
C & K BD04AV 4位置 滑动 通孔 DIP 开关, 单刀单掷, 100 mA@ 25 V 直流

贸泽:
DIP 开关/ SIP 开关 R/A STD PRO 4 POS

e络盟:
DIP / SIP开关, 4 电路, 滑动式, 通孔安装, SPST, 24 VDC, 25 mA

艾睿:
Add push button-type user control to your printed circuit board using the BD04AV dual in-line package switch from C&a;K Components. This device has a maximum current rating of 0.1 A @ 5VDC. It has a SPST configuration. This DIP switch has an operating temperature range of -40 °C to 85 °C. The BD04AV DIP switch has a PC pin termination style. The maximum DC voltage rating is 25 VDC. This product&s;s terminal pitch is 2.54 mm. This product is 12.19 mm long, 9.65 mm tall and 11.69 mm deep.

Allied Electronics:
Switch, DIP; Slide; SPST x 4 pos; 100mA 5VDC; Right angle mnt, PCB pins; Std profile

安富利:
Switch DIP OFF ON SPST 4 Extended Slide 0.1A 25VDC PC Pins 10000Cycle/SwitchCycle 2.54mm Thru-Hole Tube

Chip1Stop:
Switch DIP OFF ON SPST 4 Extended Slide 0.1A 25VDC PC Pins 10000Cycles/SwitchCycles 2.54mm Thru-Hole Tube

TME:
Switch: DIP-SWITCH; Poles number:4; OFF-ON; 0.025A/25VDC; 1GΩ

Verical:
Switch DIP OFF ON SPST 4 Extended Slide 0.1A 25VDC PC Pins 10000Cycles/SwitchCycles 2.54mm Thru-Hole Tube

Newark:
# C & K COMPONENTS  BD04AV  Slide Switch,RIGHT ANGLE,SPST,ON-OFF,Number Of Positions:4,PC TAIL Terminal,PCB Hole Count:8

儒卓力:
**DIP 4P THT raised rightangle **

MASTER:
Standard Profile DIP

Electro Sonic:
Standard Profile DIP

Win Source:
SWITCH SLIDE DIP SPST 100MA 5V / Dip Switch SPST 4 Position Through Hole, Right Angle Slide Standard Actuator 100mA 5VDC
