C 6.8uF ±10% 20V 2.5mm
Tantalum Chip Capacitors
SpeedPower, Low ESR
Features
Wide variety of Low ESR values
High ripple current capability
High volumetric efficiency
Excellent solderability
Stable temperature and frequency characteristics
Low leakage current, low dissipation factor
Low self-inductance
High resistance to shock and vibration
Suitable for use without series resistorspecial operating conditions recommended
Lead-free and material content compatible with RoHS
Some partnumbers are only available in M ±20% tolerance; these types have a maximum
capacitance drift at +125 °C of +20%
Construction
Polar tantalum capacitors with solid electrolyte
Conventional, optimized TaMnO2 technology
Flame-retardant plastic case UL 94 V-0
Optionally tinned or gold-plated terminals
Applications
Telecommunications e.g. mobile phones, infrastructure
Data processing e.g. laptops, mainframes
Measuring and control engineering e.g. voltage regulators
Automotive electronics e.g. navigation systems, electronic control units
Medical engineering
DC/DC converters
