BD06AV

DIL 开关适合波焊 适用于浸洗 “开”标签清楚地指明开/关位置 扩展执行器 非切换额定值：100mA @ 50V 直流 触点电阻：50mΩ ### 注除非另有说明，否则这些开关不适于浸泡清洗。### DIL 直通板

直角 DIL

适合波焊

适用于浸洗

“开”标签清楚地指明开/关位置

扩展执行器

非切换额定值：100mA @ 50V 直流

触点电阻：50mΩ

### 注

除非另有说明，否则这些开关不适于浸泡清洗。

得捷:
SWITCH SLIDE DIP SPST 100MA 5V

欧时:
Switch,DIL,r/a,PCB mount,6 gang

立创商城:
BD06AV

艾睿:
By acting as a series of switches, the BD06AV dual in-line package switch from C&a;K Components is the ideal component for use on a printed circuit board. This device has a maximum current rating of 0.1 A @ 5VDC. It has a SPST configuration. This DIP switch has an operating temperature range of -40 °C to 85 °C. The BD06AV DIP switch has a PC pin termination style. This product is 17.27 mm long, 9.65 mm tall and 11.69 mm deep. This product&s;s terminal pitch is 2.54 mm. The maximum DC voltage rating is 25 VDC.

Allied Electronics:
DIP SWITCH

安富利:
Switch DIP OFF ON SPST 6 Extended Slide 0.1A 25VDC PC Pins 10000Cycle/SwitchCycle 2.54mm Thru-Hole Tube

Verical:
Switch DIP OFF ON SPST 6 Extended Slide 0.1A 25VDC PC Pins 10000Cycles/SwitchCycles 2.54mm Thru-Hole Tube

Newark:
# C & K COMPONENTS  BD06AV  Slide Switch,RIGHT ANGLE,SPST,ON-OFF,Number Of Positions:6,PC TAIL Terminal,PCB Hole Count:12

儒卓力:
**DIP 6P THT raised rightangle **

MASTER:
Standard Profile DIP

Electro Sonic:
Standard Profile DIP
