Circuit Breaker, Hydraulic/Magnetic, 1Pole, Series Trip, 30A, White Act
** B-Series Circuit Breakers**
Carling Technologies B-Series hydraulic/magnetic circuit breakers are compact and temperature stable designed for precision operation in applications requiring general purpose as well as full load amp applications. The B-Series are offered with ratings from 0.02 to 50 amps and up to 277 V ac or 80 V dc, with choices of time delays, terminals, wide range of standard Colors, imprinting. Actuators available include handles for 1- 6 poles, rocker for 1-3 poles, and Visi-Rocker for 1-3 poles construction.
额定电流 30 A
额定电压 277VAC, 80VDC
Actuator Type Handle
Brand/Series B Series
Current Rating 30 A
Dimensions 2.09 L x 0.755 W x 2 H in.
Mounting Type Panel Mount/Snap-In
Number of Poles 1 Pole
Primary Type Circuit Breaker
Special Features CSA Accepted/UL Recognized/VDE Certified
Termination Screws
Time, Trip Long Delay
Type Hydraulic/Magnetic
Voltage Rating 277 VAC/80 VDC
RoHS标准 RoHS Compliant
