BAT-ANT-N-14G-IP23

BAT-ANT-N-14G-IP23图片1
BAT-ANT-N-14G-IP23图片2
BAT-ANT-N-14G-IP23图片3
BAT-ANT-N-14G-IP23概述

Antenna, 2.4GHz, Directional, 14dBi Gain, N Female, 1 Meter Cable, 943981005

Since 2005 Automation and Control GmbH has offered a steadily increasing product portfolio of wireless LAN devices. This is comprised not only of industrial-grade active devices such as Access Points and Clients. Cables, antennas, lightning protection and so on also form an integral part of the range. Together these components offer the customer the possibility to deploy simple and secure wireless installations.

**Features:**

* The Radio Coverage of the New Antennas is Considerable More Homogeneous

* The Scope of Delivery Now Consists of a Complete Solution, Including Antenna, 1 Meter Cable, and Pigtail

* Vibration-Resistant, Waterproof, and Stable Mounting Kit is Also Included

* All Antennas Comply With the IP65 Protection Class

* All Antennas are Now Equipped With N Connectors

BAT-ANT-N-14G-IP23中文资料参数规格
技术参数

增益 14 dBi

封装参数

安装方式 Panel

其他

Accessory Type Antenna

Brand/Series BAT Series

Communication N Female

Connection N Female

Connector Type N Female

For Use With BAT-2.4 GHz Band

Frequency 2400-2500 MHz

Frequency Range 2400 to 2500 MHz

Gain 14 dBi

Material, Housing Plastic

Mounting Type Mast/Panel

Power 2.0

Protection Rating IP23

Special Features 1 M Cable, Pigtail, Stable Mounting Kit is Also Included, Vibration-Resistant, Waterproof

Standards IP23

Temperature, Operating -40 to 80 Deg C

Type Antenna

数据手册

在线购买BAT-ANT-N-14G-IP23
型号: BAT-ANT-N-14G-IP23
制造商: Hirschmann
描述:Antenna, 2.4GHz, Directional, 14dBi Gain, N Female, 1 Meter Cable, 943981005
