BFP193

BFP193 NPN三极管 20V 80mA 8Ghz 50~200 SOT-143 marking/标记 RC 低噪声和高增益宽带放大器

集电极-基极反向击穿电压VBRCBOCollector-Base VoltageVCBO| 15V \---|--- 集电极-发射极反向击穿电压VBRCEOCollector-Emitter VoltageVCEO| 12V 集电极连续输出电流ICCollector CurrentIC| 80mA 截止频率fTTranstion FrequencyfT| 8Ghz 直流电流增益hFEDC Current GainhFE| 50~200 管压降VCE（sat）Collector-Emitter Saturation Voltage| 耗散功率PcPower Dissipation| 580mW/0.58W Description & Applications| NPN Silicon RF Transistor For low noise, high-gain amplifiers up to 2 GHz For linear broadband amplifiers fT = 8 GHz F = 1.3 dB at 900 MHz 描述与应用| NPN硅RF晶体管 低噪声，高增益放大器高达2 GHz 对于线性宽带放大器 FT =8 GHz的 F =1.3分贝在900 MHz时
