BTB06-600CW

SNUBBERLESS⑩ ，逻辑电平及标准 SNUBBERLESS⑩, LOGIC LEVEL & STANDARD

DESCRIPTION

Available either in through-hole or surface-mount packages, the BTA06and BTB06triac series is

suitable for general purpose AC switching. They can be used as an ON/OFF function in applica

tions such as static relays, heating regulation, in duction motor starting circuits... or for phase

control operation in light dimmers, motor speed controllers,...

The snubberless and logic level versions BTA/BTB...W are specially recommended for use on

inductive loads, thanks to their high commutation performances.

By using an internal ceramic pad, the BTA series provides voltage insulated tab rated at

2500VRMS complying with UL standards File ref.: E81734.
