BZV55-B15

稳压二极管 Voltage regulator diodes

General description

Low-power voltage regulator diodes in small hermetically sealed glass SOD80C Surface-Mounted Device SMD packages. The diodes are available in the normalized E24 ±2% BZV55-B and approximately ±5% BZV55-C tolerance range.

The series consists of 37 types with nominal working voltages from 2.4 V to 75 V.

Features and benefits

■ Non-repetitive peak reverse power dissipation: ≤ 40 W

■ Wide working voltage range: nominal 2.4 V to 75 V E24 range

■ Total power dissipation: ≤ 500 mW 

■ Low differential resistance

■ Two tolerance series: ±2 % and ±5 % 

■ Small hermetically sealed glass SMD package

Applications

■ General regulation functions
