TEXAS INSTRUMENTS CD4522BE 芯片, 逻辑芯片 - 计数器
The is a CMOS programmable BCD Divide-By-N Counter has a decoded "0" state output for divide-by-N applications. In single stage operation the "0" output is tied to the Preset Enable input. The Cascade Feedback allows multiple stage divide-by-N operation without the need for external gating. A high on the Clock Inhibit disables the pulse-counting function. A high on the Master Reset asynchronously resets the divide-by-N operation. The output is presented in BCD format.
电源电压DC 15.0 V, 18.0 V max
输出接口数 4
输出电流 6.80 mA
针脚数 16
时钟频率 4 MHz
位数 4
输入数 4
工作温度Max 125 ℃
工作温度Min -55 ℃
电源电压 3V ~ 18V
电源电压Max 18 V
电源电压Min 3 V
安装方式 Through Hole
引脚数 16
封装 PDIP-16
封装 PDIP-16
工作温度 -55℃ ~ 125℃
产品生命周期 Active
包装方式 Tube
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC标准 No SVHC
REACH SVHC版本 2015/06/15
ECCN代码 EAR99
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
CD4522BE TI 德州仪器 | 当前型号 | 当前型号 |
CD4522BEE4 德州仪器 | 类似代替 | CD4522BE和CD4522BEE4的区别 |
CD4522BEG4 德州仪器 | 功能相似 | CD4522BE和CD4522BEG4的区别 |
