PROM 串行 I²C,ON Semiconductor### EEPROM 串行存取 - ON Semiconductor
电可擦除 PROM 串行 I²C,
得捷:
IC EEPROM 4KBIT I2C 400KHZ 8DIP
欧时:
### 电可擦除 PROM 串行 I²C,ON Semiconductor### EEPROM 串行存取 - ON Semiconductor
贸泽:
EEPROM 512x8 4K 1.8-5.5
艾睿:
EEPROM Serial-I2C 4K-bit 512 x 8 1.8V/2.5V/3.3V/5V 8-Pin PDIP Tube
富昌:
CAT24C 系列 4 Kb 32 X 128 1.7 至 5.5 V I2C 总线 CMOS 串行 EEPROM - PDIP-8
Chip1Stop:
EEPROM Serial-I2C 4K-bit 512 x 8 1.8V/2.5V/3.3V/5V Automotive 8-Pin PDIP Tube
Verical:
EEPROM Serial-I2C 4K-bit 512 x 8 1.8V/2.5V/3.3V/5V Automotive 8-Pin PDIP Tube
频率 0.4 MHz
电源电压DC 1.70V min
无卤素状态 Halogen Free
供电电流 2 mA
时钟频率 400 kHz
存取时间 900 ns
内存容量 500 B
存取时间Max 900 ns
工作温度Max 85 ℃
工作温度Min -40 ℃
电源电压 1.7V ~ 5.5V
电源电压Max 5.5 V
电源电压Min 1.7 V
安装方式 Through Hole
引脚数 8
封装 PDIP-8
长度 10.16 mm
宽度 7.11 mm
高度 4.95 mm
封装 PDIP-8
工作温度 -40℃ ~ 85℃ TA
产品生命周期 Active
包装方式 Tube
制造应用 TV, Alarm Systems, Two Way Radios, Hard Disk Drives, Notebook PC, Wireless LANs, Set Top Box, Cellular Phones, Memory Modules, Printers, CDRW, Vending Machines, Internet Phone Handsets, Health Mete, Video Tape Recorder, Heal, Audio Players, Cable Modems, Personal Computers, DRAM Modules, Video Games
RoHS标准 RoHS Compliant
含铅标准 Lead Free
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
CAT24C04LI-G ON Semiconductor 安森美 | 当前型号 | 当前型号 |
CAT24C04WI-GT3 安森美 | 完全替代 | CAT24C04LI-G和CAT24C04WI-GT3的区别 |
CAT24C04YI-GT3 安森美 | 完全替代 | CAT24C04LI-G和CAT24C04YI-GT3的区别 |
CAT24C04WI-G 安森美 | 完全替代 | CAT24C04LI-G和CAT24C04WI-G的区别 |
