350mA大电流降压LED驱动
直流-直流 LED 驱动器，
得捷:
IC LED DRV RGLTR ANALOG TSOT23-5
立创商城:
LED 驱动器，350 mA，步降转换器
欧时:
ON Semiconductor CAT4201TD-GT3 1段 LED 显示驱动器, 6.5 → 36 V, 5引脚 TSOT-23封装
艾睿:
LED Driver 1 Segment 1000uA Supply Current Automotive 5-Pin TSOT-23 T/R
Allied Electronics:
CAT4201TD-GT3, LED Display Driver 1-Segments, 6.5 - 36 V, 5-Pin TSOT-23
安富利:
LED DRVR 1Segment 9V/12V/15V/18V/24V 5-Pin TSOT-23 T/R
Chip1Stop:
LED DRVR 1Segment 9V/12V/15V/18V/24V 5-Pin TSOT-23 T/R
TME:
Driver; LED controller; TSOT23-5
Verical:
LED Driver 1 Segment 1000uA Supply Current Automotive 5-Pin TSOT-23 T/R
Newark:
LED DRIVER, BUCK, 350mA, TSOT-23-5
力源芯城:
350mA大电流降压LED驱动
DeviceMart:
IC LED DRIVER HIGH BRIGHT TSOT-5
Win Source:
LED Driver IC 1 Output DC DC Regulator Step-Down Buck Analog Dimming 350mA TSOT-23-5
频率 50kHz ~ 1MHz
无卤素状态 Halogen Free
输出接口数 1
输入电压DC 6.50V ~ 36.0V
输出电压 36 V
输出电流 350 mA
供电电流 1000 mA
开关频率 1 MHz
拓扑结构 Step-Down
输入电压Max 36 V
输入电压Min 0 V
输出电压Max 32 V
输出电流Max 350 mA
工作温度Max 125 ℃
工作温度Min -40 ℃
电源电压 6.5V ~ 36V
电源电压Max 36 V
电源电压Min 6.5 V
安装方式 Surface Mount
引脚数 5
封装 TSOT-23-5
长度 2.9 mm
宽度 2.8 mm
高度 0.9 mm
封装 TSOT-23-5
工作温度 -40℃ ~ 125℃ TA
产品生命周期 Active
包装方式 Tape & Reel TR
制造应用 Lighting, Lighting, Automotive, 照明, 12 V and 24 V Lighting Systems, Automotive, High Brightness 350 mA LEDs
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC标准 No SVHC
ECCN代码 EAR99
