0603 1uF ±10% 25V X7R
±10% 25V 陶瓷器 X7R 0603（1608 公制）
得捷:
CAP CER 1UF 25V X7R 0603
艾睿:
This CL10B105KA8NNNL multilayer ceramic capacitor from Samsung Electro-Mechanics offers high stability and low losses for resonant circuit applications. It can withstand a voltage of 25 VDC. This MLCC capacitor has a maximum operating temperature of 125 °C. This product will be shipped in tape and reel packaging so that components can be mounted effectively. It has a tolerance of 10%. Its capacitance value is 1uF. This product is 1.6 mm long, 0.8 mm tall and 0.8 mm deep.
Verical:
Cap Ceramic 1uF 25V X7R 10% Pad SMD 0603 125C T/R
额定电压DC 25.0 V
电容 1000000 PF
容差 ±10 %
电介质特性 X7R
工作温度Max 125 ℃
工作温度Min -55 ℃
额定电压 25 V
安装方式 Surface Mount
封装公制 1608
封装 0603
长度 1.6 mm
宽度 0.8 mm
高度 0.8 mm
封装公制 1608
封装 0603
厚度 0.8 mm
材质 X7R/-55℃~+125℃
工作温度 -55℃ ~ 125℃
产品生命周期 Active
包装方式 Tape & Reel TR
最小包装 15000
制造应用 通用
RoHS标准 RoHS Compliant
含铅标准 Lead Free
| 型号/品牌 | 代替类型 | 替代型号对比 |
|---|---|---|
CL10B105KA8NNNL Samsung 三星 | 当前型号 | 当前型号 |
CL10A105KA8NNNC 三星 | 类似代替 | CL10B105KA8NNNL和CL10A105KA8NNNC的区别 |
CL10B105KA8NNNC 三星 | 类似代替 | CL10B105KA8NNNL和CL10B105KA8NNNC的区别 |
CL10A105KA8NNNL 三星 | 类似代替 | CL10B105KA8NNNL和CL10A105KA8NNNL的区别 |
