0201 15nF ±10% 10V X5R
0.015µF ±10% 10V Ceramic Capacitor X5R 0201 0603 Metric
得捷:
CAP CER 0.015UF 10V X5R 0201
艾睿:
With alternating layers of ceramic acting as the dielectric and electrodes, this C0603X5R1A153K030BC multilayer ceramic capacitor from TDK achieves a large capacitance in a small package. It can withstand a voltage of 10 VDC. This MLCC capacitor has a maximum operating temperature of 85 °C. Tape and reel packaging will encase the product during shipment, ensuring safe delivery and enabling quick mounting of components. This product is 0.6 mm long, 0.3 mm tall and 0.3 mm deep. Its capacitance value is 0.015uF. It has a tolerance of 10%.
安富利:
Cap Ceramic 0.015uF 10V X5R 10% SMD 0201 85°C Punched Paper T/R
Verical:
Cap Ceramic 0.015uF 10V X5R 10% Pad SMD 0201 85C Low ESR T/R
额定电压DC 10.0 V
电容 0.015 µF
容差 ±10 %
电介质特性 X5R
工作温度Max 85 ℃
工作温度Min -55 ℃
额定电压 10 V
安装方式 Surface Mount
封装 0201
长度 600 µm
宽度 300 µm
高度 0.3 mm
封装 0201
厚度 0.3 mm
材质 X5R/-55℃~+85℃
介质材料 Ceramic Multilayer
工作温度 -55℃ ~ 85℃
产品生命周期 Production Not Recommended for New Design
包装方式 Tape & Reel TR
最小包装 15000
制造应用 通用, Commercial Grade
RoHS标准 RoHS Compliant
含铅标准 Lead Free
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
C0603X5R1A153K030BC TDK 东电化 | 当前型号 | 当前型号 |
GRM033R61A153KE84D 村田 | 类似代替 | C0603X5R1A153K030BC和GRM033R61A153KE84D的区别 |
C0603X5R0J153K030BA 东电化 | 功能相似 | C0603X5R1A153K030BC和C0603X5R0J153K030BA的区别 |
GRM033R61A153KE84J 村田 | 功能相似 | C0603X5R1A153K030BC和GRM033R61A153KE84J的区别 |
