0603 15nF ±10% 50V X7R
±10% 50V 陶瓷器 X7R 0603（1608 公制）
得捷:
CAP CER 0.015UF 50V X7R 0603
艾睿:
You can&s;t go wrong with this C1608X7R1H153K080AA multilayer ceramic capacitor from TDK, it is the most commonly used type of capacitor for multiple applications! It can withstand a voltage of 50 VDC. This MLCC capacitor has a maximum operating temperature of 125 °C. This component will be shipped in tape and reel packaging for effective mounting and safe delivery. It has a tolerance of 10%. Its capacitance value is 0.015uF. This product is 1.6 mm long, 0.8 mm tall and 0.8 mm deep.
Verical:
Cap Ceramic 0.015uF 50V X7R 10% Pad SMD 0603 125C Low ESR T/R
Electro Sonic:
Cap Ceramic 0.015uF 50V X7R 10% SMD 0603 125°C T/R
额定电压DC 50.0 V
电容 0.015 µF
容差 ±10 %
电介质特性 X7R
工作温度Max 125 ℃
工作温度Min -55 ℃
额定电压 50 V
安装方式 Surface Mount
封装公制 1608
封装 0603
长度 1.60 mm
宽度 800 µm
高度 0.8 mm
封装公制 1608
封装 0603
厚度 0.8 mm
材质 X7R/-55℃~+125℃
介质材料 Ceramic Multilayer
工作温度 -55℃ ~ 125℃
产品生命周期 Production Not Recommended for New Design
包装方式 Tape & Reel TR
最小包装 4000
制造应用 通用, for Automotive use., Please refer to Part No., Commercial Grade
RoHS标准 RoHS Compliant
含铅标准 Lead Free
| 型号/品牌 | 代替类型 | 替代型号对比 |
|---|---|---|
C1608X7R1H153K080AA TDK 东电化 | 当前型号 | 当前型号 |
C1608X7R1H153M080AA 东电化 | 类似代替 | C1608X7R1H153K080AA和C1608X7R1H153M080AA的区别 |
C0603C153K5RACAUTO 基美 | 类似代替 | C1608X7R1H153K080AA和C0603C153K5RACAUTO的区别 |
06035C153KAJ4A 艾维克斯 | 类似代替 | C1608X7R1H153K080AA和06035C153KAJ4A的区别 |
