TDK CGA3E2X7R2A152K080AA 多层陶瓷电容器, 表面贴装, CGA系列, 1500 pF, ± 10%, X7R, 100 V, 0603 [1608 公制]
1500pF ±10% 100V Ceramic Capacitor X7R 0603 1608 Metric
得捷:
CAP CER 1500PF 100V X7R 0603
立创商城:
1.5nF ±10% 100V
e络盟:
TDK CGA3E2X7R2A152K080AA 多层陶瓷电容器, 表面贴装, CGA系列, 1500 pF, ± 10%, X7R, 100 V, 0603 [1608 公制]
艾睿:
Do you need a capacitor with high stability and low losses? Then this CGA3E2X7R2A152K080AA multilayer ceramic capacitor from TDK is the solution you are looking for! It can withstand a voltage of 100 VDC. This MLCC capacitor has a maximum operating temperature of 125 °C. This component will be shipped in tape and reel packaging to allow for effective mounting and safe delivery. It has a tolerance of 10%. Its capacitance value is 0.0015uF. This product is 1.6 mm long, 0.8 mm tall and 0.8 mm deep.
Verical:
Cap Ceramic 0.0015uF 100V X7R 10% Pad SMD 0603 125C Automotive T/R
额定电压DC 100 V
电容 1500 pF
容差 ±10 %
电介质特性 X7R
工作温度Max 125 ℃
工作温度Min -55 ℃
额定电压 100 V
安装方式 Surface Mount
封装公制 1608
封装 0603
长度 1.6 mm
宽度 0.8 mm
高度 0.8 mm
封装公制 1608
封装 0603
材质 X7R/-55℃~+125℃
工作温度 -55℃ ~ 125℃
产品生命周期 Production Not Recommended for New Design
包装方式 Cut Tape CT
最小包装 4000
制造应用 Automotive Grade
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC标准 No SVHC
REACH SVHC版本 2015/06/15
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
CGA3E2X7R2A152K080AA TDK 东电化 | 当前型号 | 当前型号 |
C0603C152K1RACTU 基美 | 类似代替 | CGA3E2X7R2A152K080AA和C0603C152K1RACTU的区别 |
C1608X7R2A152K080AA 东电化 | 类似代替 | CGA3E2X7R2A152K080AA和C1608X7R2A152K080AA的区别 |
CC0603KRX7R0BB152 国巨 | 类似代替 | CGA3E2X7R2A152K080AA和CC0603KRX7R0BB152的区别 |
