CLC1002ISO8X

单路高性能电压反馈放大器

General Description

The COMLINEAR CLC1002single is a high-performance, voltage feedback amplifer with ultra-low input voltage noise, 0.6nV/√Hz. The CLC1002 provides 965MHz gain bandwidth product and 170V/μs slew rate making it well suited for high-speed data acquisition systems requiring high levels of sensitivity and signal integrity. This COMLINEAR high-performance amplifer also offers low input offset voltage.

The COMLINEAR CLC1002 is designed to operate from 4V to 12V supplies. It consumes only 13mA of supply current per channel and offers a power saving disable pin that disables the amplifer and decreases the supply current to below 225μA. The CLC1002 amplifer operates over the extended temperature range of -40°C to +125°C.

If larger bandwidth or slew rate is required, a higher minimum stable gain version is available, the CLC1001 offers a minimum stable gain of 10 with 2.1GHz GBWP and 410V/μs slew rate.

FEATURES

▪ 0.6 nV/√Hz input voltage noise

▪ 1mV maximum input offset voltage

▪ 965MHz gain bandwidth product

▪ Minimum stable gain of 5

▪ 170V/μs slew rate

▪ 130mA output current

▪ -40°C to +125°C operating temperature range

▪ Fully specifed at 5V and ±5V supplies

▪ CLC1002: Lead-free SOT23-6

APPLICATIONS

▪ Transimpedance amplifers

▪ Pre-amplifer

▪ Low noise signal processing

▪ Medical instrumentation

▪ Probe equipment

▪ Test equipment

▪ Ultrasound channel amplifer
