1206 0.018 uF 50 V 10 % 容差 X7R SMD 陶瓷电容
MLCC-多层陶瓷器
立创商城:
18nF ±10% 50V
得捷:
CAP CER 0.018UF 50V X7R 1206
艾睿:
Do you need a non-polarized capacitor? This CC1206KRX7R9BB183 multilayer ceramic capacitor from Yageo can be connected either to positive or to negative voltage as you please! It can withstand a voltage of 50 VDC. This MLCC capacitor has a maximum operating temperature of 125 °C. This component will be shipped in tape and reel packaging for effective mounting and safe delivery. Its capacitance value is 0.018uF. This product is 3.2 mm long, 0.85 mm tall and 1.6 mm deep. It has a tolerance of 10%.
安富利:
Cap Ceramic 0.018uF 50V X7R 10% SMD 1206 125°C Paper T/R
Verical:
Cap Ceramic 0.018uF 50V X7R 10% Pad SMD 1206 125C T/R
额定电压DC 50.0 V
绝缘电阻 10 GΩ
电容 0.018 µF
容差 ±10 %
无卤素状态 Halogen Free
电介质特性 X7R
工作温度Max 125 ℃
工作温度Min -55 ℃
额定电压 50 V
安装方式 Surface Mount
封装公制 3216
封装 1206
长度 3.20 mm
宽度 1.6 mm
高度 0.85 mm
封装公制 3216
封装 1206
材质 X7R/-55℃~+125℃
工作温度 -55℃ ~ 125℃
产品生命周期 Active
包装方式 Tape & Reel TR
最小包装 4000
制造应用 通用
RoHS标准 RoHS Compliant
含铅标准 Lead Free
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
CC1206KRX7R9BB183 Yageo 国巨 | 当前型号 | 当前型号 |
CC1206KPX7R9BB183 国巨 | 功能相似 | CC1206KRX7R9BB183和CC1206KPX7R9BB183的区别 |
VJ1206Y183KXAMR Vishay Vitramon | 功能相似 | CC1206KRX7R9BB183和VJ1206Y183KXAMR的区别 |
