0603 6.8pF ±0.5pF 50V NPO
6.8 pF ±0.5pF 50V 陶瓷器 C0G，NP0 0603（1608 公制）
得捷:
CAP CER 6.8PF 50V NP0 0603
立创商城:
6.8pF ±0.5pF 50V
艾睿:
This CGA3E2NP01H6R8D080AA multilayer ceramic capacitor from TDK can be used in multiple applications and for various purposes. It can withstand a voltage of 50 VDC. This MLCC capacitor has a maximum operating temperature of 150 °C. In order to ensure safe delivery and enable quick mounting of this component after delivery, it will be encased in tape and reel packaging during shipment. Its capacitance value is 6.8pF. This product is 1.6 mm long, 0.8 mm tall and 0.8 mm deep.
Verical:
Cap Ceramic 6.8pF 50V C0G 0.5pF Pad SMD 0603 150C Automotive T/R
额定电压DC 50 V
电容 6.8 pF
容差 ±0.5 pF
工作温度Max 150 ℃
工作温度Min -55 ℃
额定电压 50 V
安装方式 Surface Mount
封装公制 1608
封装 0603
长度 1.6 mm
宽度 0.8 mm
高度 0.8 mm
封装公制 1608
封装 0603
材质 NP0/-55℃~+125℃
工作温度 -55℃ ~ 150℃
产品生命周期 Production Not Recommended for New Design
包装方式 Tape & Reel TR
最小包装 4000
制造应用 汽车级, Automotive Grade
RoHS标准 RoHS Compliant
含铅标准 Lead Free
| 型号/品牌 | 代替类型 | 替代型号对比 |
|---|---|---|
CGA3E2NP01H6R8D080AA TDK 东电化 | 当前型号 | 当前型号 |
CGA3E2C0G1H6R8D080AA 东电化 | 类似代替 | CGA3E2NP01H6R8D080AA和CGA3E2C0G1H6R8D080AA的区别 |
GCM1885C1H6R8DZ13D 村田 | 功能相似 | CGA3E2NP01H6R8D080AA和GCM1885C1H6R8DZ13D的区别 |
CGA3E2C0G2A6R8D080AA 东电化 | 功能相似 | CGA3E2NP01H6R8D080AA和CGA3E2C0G2A6R8D080AA的区别 |
