0805 150nF ±10% 50V X7R
0.15µF ±10% 50V Ceramic Capacitor X7R 0805 2012 Metric
得捷:
CAP CER 0.15UF 50V X7R 0805
立创商城:
150nF ±10% 50V
艾睿:
Do you need a non-polarized capacitor? This C2012X7R1H154K125AA multilayer ceramic capacitor from TDK can be connected either to positive or to negative voltage as you please! It can withstand a voltage of 50 VDC. This MLCC capacitor has a maximum operating temperature of 125 °C. This component will be shipped in tape and reel packaging to allow for effective mounting and safe delivery. This product is 2 mm long, 1.25 mm tall and 1.25 mm deep. Its capacitance value is 0.15uF. It has a tolerance of 10%.
安富利:
CAP .15UF 50VDC X7R 10% SMD 0805
Verical:
Cap Ceramic 0.15uF 50V X7R 10% Pad SMD 0805 125C Low ESR T/R
Newark:
# TDK C2012X7R1H154K125AA SMD Multilayer Ceramic Capacitor, 0805 [2012 Metric], 0.15 µF, 50 V, ± 10%, X7R, C Series
MASTER:
Cap Ceramic 0.15uF 50V X7R 10% SMD 0805 125°C T/R
Electro Sonic:
Cap Ceramic 0.15uF 50V X7R 10% SMD 0805 125°C T/R
额定电压DC 50.0 V
电容 0.15 µF
容差 ±10 %
电介质特性 X7R
工作温度Max 125 ℃
工作温度Min -55 ℃
额定电压 50 V
安装方式 Surface Mount
引脚数 2
封装公制 2012
封装 0805
长度 2.00 mm
宽度 1.25 mm
高度 1.25 mm
封装公制 2012
封装 0805
厚度 1.25 mm
材质 X7R/-55℃~+125℃
介质材料 Ceramic Multilayer
工作温度 -55℃ ~ 125℃
产品生命周期 Production Not Recommended for New Design
包装方式 Tape & Reel TR
最小包装 3000
制造应用 Commercial Grade, Please refer to Part No., for Automotive use.
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC版本 2015/06/15
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
C2012X7R1H154K125AA TDK 东电化 | 当前型号 | 当前型号 |
GRM21BR71H154KA01L 村田 | 类似代替 | C2012X7R1H154K125AA和GRM21BR71H154KA01L的区别 |
0805B154K500CT 台湾华科 | 类似代替 | C2012X7R1H154K125AA和0805B154K500CT的区别 |
CGA4J2X7R1H154K125AA 东电化 | 功能相似 | C2012X7R1H154K125AA和CGA4J2X7R1H154K125AA的区别 |
