0603 4.7pF ±0.25pF 100V NPO
4.7pF ±0.25pF 100V Ceramic Capacitor C0G, NP0 0603 1608 Metric
得捷:
CAP CER 4.7PF 100V NP0 0603
立创商城:
4.7pF ±0.25pF 100V
艾睿:
You can&s;t go wrong with this C1608NP02A4R7C080AA multilayer ceramic capacitor from TDK, it is the most commonly used type of capacitor for multiple applications! It can withstand a voltage of 100 VDC. This MLCC capacitor has a maximum operating temperature of 150 °C. This product will be shipped in tape and reel packaging for quick mounting and safe delivery. Its capacitance value is 4.7pF. This product is 1.6 mm long, 0.8 mm tall and 0.8 mm deep.
Verical:
Cap Ceramic 4.7pF 100V C0G 0.25pF Pad SMD 0603 150C T/R
额定电压DC 100 V
电容 4.7 pF
容差 ±0.25 pF
工作温度Max 150 ℃
工作温度Min -55 ℃
额定电压 100 V
安装方式 Surface Mount
封装公制 1608
封装 0603
长度 1.6 mm
宽度 0.8 mm
高度 0.8 mm
封装公制 1608
封装 0603
材质 NP0/-55℃~+125℃
工作温度 -55℃ ~ 150℃
产品生命周期 Production Not Recommended for New Design
包装方式 Tape & Reel TR
最小包装 4000
制造应用 Please refer to Part No., 通用, for Automotive use., Commercial Grade
RoHS标准 RoHS Compliant
含铅标准 Lead Free
| 型号/品牌 | 代替类型 | 替代型号对比 |
|---|---|---|
C1608NP02A4R7C080AA TDK 东电化 | 当前型号 | 当前型号 |
C1608C0G2A4R7C080AA 东电化 | 类似代替 | C1608NP02A4R7C080AA和C1608C0G2A4R7C080AA的区别 |
C1608C0G1H4R7C 东电化 | 功能相似 | C1608NP02A4R7C080AA和C1608C0G1H4R7C的区别 |
C1608NP01H4R7C080AA 东电化 | 功能相似 | C1608NP02A4R7C080AA和C1608NP01H4R7C080AA的区别 |
