1206 0.0022 uF 100 V ±10 % 容差 X7R 表面贴装 陶瓷 电容
MLCC-多层陶瓷器
欧时:
MLCC Commercial 1206 +-10% 100V 2.2nF X7
得捷:
CAP CER 2200PF 100V X7R 1206
立创商城:
2.2nF ±10% 100V
贸泽:
Multilayer Ceramic Capacitors MLCC - SMD/SMT 2.2nF 100V X7R 10%
艾睿:
Get more with less with Yageo&s;s CC1206KRX7R0BB222 multilayer ceramic capacitor which uses multiple layers of ceramic and metal to act as dielectric and electrodes. It can withstand a voltage of 100 VDC. This MLCC capacitor has a maximum operating temperature of 125 °C. This product will be shipped in tape and reel packaging to allow for quick mounting and safe delivery. Its capacitance value is 0.0022uF. This product is 3.2 mm long, 0.85 mm tall and 1.6 mm deep. It has a tolerance of 10%.
安富利:
Cap Ceramic 0.0022uF 100V X7R 10% SMD 1206 125°C Paper T/R
Chip1Stop:
Cap Ceramic 0.0022uF 100V X7R 10% SMD 1206 125ÂÂ℃ Paper T/R
Verical:
Cap Ceramic 0.0022uF 100V X7R 10% Pad SMD 1206 125C T/R
儒卓力:
**KC 2,2nF 1206 10% 100V X7R **
Win Source:
CAP CER 2200PF 100V X7R 1206 / 2200 pF ±10% 100V Ceramic Capacitor X7R 1206 3216 Metric
额定电压DC 100 V
绝缘电阻 10 GΩ
电容 2200 pF
容差 ±10 %
产品系列 HV
工作温度Max 125 ℃
工作温度Min -55 ℃
精度 ±10 %
额定电压 100 V
安装方式 Surface Mount
封装公制 3216
封装 1206
长度 3.2 mm
宽度 1.6 mm
高度 0.85 mm
封装公制 3216
封装 1206
材质 X7R/-55℃~+125℃
工作温度 -55℃ ~ 125℃
产品生命周期 Active
包装方式 Tape & Reel TR
最小包装 4000
制造应用 通用
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ECCN代码 EAR99
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
CC1206KRX7R0BB222 Yageo 国巨 | 当前型号 | 当前型号 |
12061C222KAT2A 艾维克斯 | 功能相似 | CC1206KRX7R0BB222和12061C222KAT2A的区别 |
CC1206KRX7RABB222 国巨 | 功能相似 | CC1206KRX7R0BB222和CC1206KRX7RABB222的区别 |
CC1206KRX7R9BB222 国巨 | 功能相似 | CC1206KRX7R0BB222和CC1206KRX7R9BB222的区别 |
