0402 470nF ±10% 6.3V X6S
0.47 µF ±10% 6.3V 陶瓷器 X6S 0402（1005 公制）
得捷:
CAP CER 0.47UF 6.3V X6S 0402
立创商城:
470nF ±10% 6.3V
艾睿:
This CGB2A3X6S0J474K033BB multilayer ceramic capacitor from TDK is non-polarized so it may be connected either to positive or to negative voltage. It can withstand a voltage of 6.3 VDC. This MLCC capacitor has a maximum operating temperature of 105 °C. This component will be shipped in tape and reel packaging to allow for effective mounting and safe delivery. Its capacitance value is 0.47uF. This product is 1 mm long, 0.33Max mm tall and 0.5 mm deep. It has a tolerance of 10%.
额定电压DC 6.3 V
电容 0.47 µF
容差 ±10 %
工作温度Max 105 ℃
工作温度Min -55 ℃
额定电压 6.3 V
安装方式 Surface Mount
封装公制 1005
封装 0402
长度 1 mm
宽度 0.5 mm
高度 0.33 mm
封装公制 1005
封装 0402
厚度 0.3 mm
材质 X6S/-55℃~+105℃
工作温度 -55℃ ~ 105℃
产品生命周期 Active
包装方式 Tape & Reel TR
最小包装 10000
制造应用 通用, Commercial Grade
RoHS标准 RoHS Compliant
含铅标准 Lead Free
| 型号/品牌 | 代替类型 | 替代型号对比 |
|---|---|---|
CGB2A3X6S0J474K033BB TDK 东电化 | 当前型号 | 当前型号 |
CGB2A3X6S0J474M033BB 东电化 | 类似代替 | CGB2A3X6S0J474K033BB和CGB2A3X6S0J474M033BB的区别 |
CGB2T1X6S0G474M022BC 东电化 | 功能相似 | CGB2A3X6S0J474K033BB和CGB2T1X6S0G474M022BC的区别 |
CGB2A1X6S0G474M033BC 东电化 | 功能相似 | CGB2A3X6S0J474K033BB和CGB2A1X6S0G474M033BC的区别 |
