0805 1nF ±10% 100V X7R
±10% 100V 陶瓷器 X7R 0805（2012 公制）
得捷:
CAP CER 1000PF 100V X7R 0805
立创商城:
1nF ±10% 100V
艾睿:
You can&s;t go wrong with this C2012X7R2A102K085AM multilayer ceramic capacitor from TDK, it is the most commonly used type of capacitor for multiple applications! It can withstand a voltage of 100 VDC. This MLCC capacitor has a maximum operating temperature of 125 °C. This product will be shipped in tape and reel packaging to allow for quick mounting and safe delivery. Its capacitance value is 0.001uF. This product is 2 mm long, 0.85 mm tall and 1.25 mm deep. It has a tolerance of 10%.
Verical:
Cap Ceramic 0.001uF 100V X7R 10% Pad SMD 0805 125C T/R
儒卓力:
**KC 1,0nF 0805 10% 100V X7R OM **
额定电压DC 100 V
电容 1000 pF
容差 ±10 %
电介质特性 X7R
工作温度Max 125 ℃
工作温度Min -55 ℃
额定电压 100 V
安装方式 Surface Mount
引脚数 2
封装公制 2012
封装 0805
长度 2 mm
宽度 1.25 mm
高度 0.85 mm
封装公制 2012
封装 0805
厚度 0.85 mm
材质 X7R/-55℃~+125℃
工作温度 -55℃ ~ 125℃
产品生命周期 Production Not Recommended for New Design
包装方式 Tape & Reel TR
最小包装 4000
制造应用 Boardflex 敏感, 通用, Commercial Grade
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ECCN代码 EAR99
| 型号/品牌 | 代替类型 | 替代型号对比 |
|---|---|---|
C2012X7R2A102K085AM TDK 东电化 | 当前型号 | 当前型号 |
C0805Y102K1RACTU 基美 | 类似代替 | C2012X7R2A102K085AM和C0805Y102K1RACTU的区别 |
CL21B102KCANNNC 三星 | 功能相似 | C2012X7R2A102K085AM和CL21B102KCANNNC的区别 |
C2012X7R2E102K085AM 东电化 | 功能相似 | C2012X7R2A102K085AM和C2012X7R2E102K085AM的区别 |
