0805 4.7nF ±10% 250V X7R
4700pF ±10% 250V Ceramic Capacitor X7R 0805 2012 Metric
得捷:
CAP CER 4700PF 250V X7R 0805
艾睿:
Use TDK&s;s C2012X7R2E472K085AM multilayer ceramic capacitor for various purposes in multiple applications. It can withstand a voltage of 250 VDC. This MLCC capacitor has a maximum operating temperature of 125 °C. In order to ensure safe delivery and enable quick mounting of this component after delivery, it will be encased in tape and reel packaging during shipment. It has a tolerance of 10%. This product is 2 mm long, 0.85 mm tall and 1.25 mm deep. Its capacitance value is 0.0047uF.
Verical:
Cap Ceramic 0.0047uF 250V X7R 10% Pad SMD 0805 125C T/R
额定电压DC 250 V
电容 4700 PF
容差 ±10 %
电介质特性 X7R
工作温度Max 125 ℃
工作温度Min -55 ℃
额定电压 250 V
安装方式 Surface Mount
引脚数 2
封装公制 2012
封装 0805
长度 2 mm
宽度 1.25 mm
高度 0.85 mm
封装公制 2012
封装 0805
厚度 0.85 mm
材质 X7R/-55℃~+125℃
工作温度 -55℃ ~ 125℃
产品生命周期 Production Not Recommended for New Design
包装方式 Tape & Reel TR
最小包装 4000
制造应用 Boardflex 敏感, Commercial Grade
RoHS标准 RoHS Compliant
含铅标准 Lead Free
| 型号/品牌 | 代替类型 | 替代型号对比 |
|---|---|---|
C2012X7R2E472K085AM TDK 东电化 | 当前型号 | 当前型号 |
C2012X7R2E472K085AA 东电化 | 类似代替 | C2012X7R2E472K085AM和C2012X7R2E472K085AA的区别 |
CC0805KRX7RYBB472 国巨 | 类似代替 | C2012X7R2E472K085AM和CC0805KRX7RYBB472的区别 |
C2012X7R2A472K085AM 东电化 | 类似代替 | C2012X7R2E472K085AM和C2012X7R2A472K085AM的区别 |
