CY22381FXIT

Flash、Field可编程,频率可选,输出使能,节能管理

Functional Description

The CY22381 is the next-generation programmable Flash programmable clock for use in networking, telecommunication, datacom, and other general-purpose applications. The CY22381 offers up to three configurable outputs in a 8-pin SOIC, running off a 3.3 V power supply. The on-chip reference oscillator is designed to run off an 8–30-MHz crystal, or a 1–166-MHz external clock signal. The CY22381 has a three PLLs driving 3 programmable output clocks. The output clocks are derived from the PLL or the reference frequency REF. Output post dividers are available for either. The CY223811 is the CY22381 with NiPdAu lead finish.

Features

■ Three integrated phase-locked loops

■ Ultra-wide divide counters eight-bit Q, eleven-bit P, and seven-bit post divide

■ Improved linear crystal load capacitors

■ Flash programmability

■ Field programmability

■ Low-jitter, high-accuracy outputs

■ Power-management options Shutdown, OE, Suspend

■ Configurable crystal drive strength

■ Frequency select option through external LVTTL Input

■ 3.3 V operation

■ 8-pin small outline integrated circuit SOIC package CY22381

■ 8-pin SOIC package with NiPdAu lead finish CY223811

■ CyClocks RT™ support
