KEMET C0603C221K4RACTU CAP, MLCC, X7R, 220PF, 16V, 0603 新
SMD Comm X7R, Ceramic, Commercial Grade, 220 pF, 10%, 16 VDC, X7R, SMD, MLCC, Temperature Stable, Class II, 0603
立创商城:
220pF ±10% 16V
得捷:
CAP CER 220PF 16V X7R 0603
e络盟:
多层陶瓷电容器, 表面贴装, 220 pF, 16 V, 0603 [1608 公制], ± 10%, X7R, C系列KEMET
艾睿:
This C0603C221K4RACTU multilayer ceramic capacitor from Kemet has so many uses that it even has a standard classification system for all its uses! It can withstand a voltage of 16 VDC. This MLCC capacitor has a maximum operating temperature of 125 °C. This component will be shipped in tape and reel packaging to allow for effective mounting and safe delivery. It has a tolerance of 10%. This product is 1.6 mm long, 0.8 mm tall and 0.8 mm deep. Its capacitance value is 220pF.
安富利:
Cap Ceramic 220pF 16V X7R 10% SMD 0603 125°C Paper T/R
Verical:
Cap Ceramic 220pF 16V X7R 10% Pad SMD 0603 125C T/R
Newark:
# KEMET C0603C221K4RACTU SMD Multilayer Ceramic Capacitor, 0603 [1608 Metric], 220 pF, 16 V, ± 10%, X7R, C Series New
额定电压DC 16.0 V
绝缘电阻 100 GΩ
电容 220 pF
容差 ±10 %
电介质特性 X7R
工作温度Max 125 ℃
工作温度Min -55 ℃
额定电压 16 V
安装方式 Surface Mount
封装公制 1608
封装 0603
引脚间距 0.7 mm
长度 1.6 mm
宽度 1.6 mm
高度 0.8 mm
封装公制 1608
封装 0603
引脚间距 0.7 mm
介质材料 Ceramic
工作温度 -55℃ ~ 125℃
产品生命周期 Active
包装方式 Cut Tape CT
制造应用 通用, 旁通,去耦
RoHS标准 RoHS Compliant
含铅标准
REACH SVHC版本 2015/06/15
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
C0603C221K4RACTU KEMET Corporation 基美 | 当前型号 | 当前型号 |
CC0603KRX7R7BB221 国巨 | 类似代替 | C0603C221K4RACTU和CC0603KRX7R7BB221的区别 |
C0603C221J4RACTU 基美 | 类似代替 | C0603C221K4RACTU和C0603C221J4RACTU的区别 |
C0603C221K5RACTU 基美 | 功能相似 | C0603C221K4RACTU和C0603C221K5RACTU的区别 |
