CW201212-R22J

BOURNS  CW201212-R22J  表面贴装高频电感器, CW201212系列, 220 nH, ± 5%, 0805 [2012 公制], 860 MHz, 1.1 ohm

Inductor Chip Wirewound 220nH 5% 100MHz 50Q-Factor Ferrite 300mA 1.1Ohm DCR 0805 T/R

得捷:
FIXED IND 220NH 300MA 1.1OHM SMD

立创商城:
220nH ±5% 1Ω

e络盟:
高频电感器, 220 nH, CW201212 Series, 300 mA, 0805 [2012 公制], 多层, 1.1 ohm

艾睿:
An ideal space-saving electronic component is this chip CW201212-R22J surface mount inductor from Bourns. This SMD inductor has an operating temperature range of -40 °C to 125 °C. Tape and reel packaging will encase this product during shipment, in order to ensure safe delivery and enable quick mounting of components. It has an inductance of 220n H. This product is 2.3 mm long, 1.5 mm tall and 1.7 mm deep. Its test frequency is 100M Hz, while its minimum self-resonant frequency is 860M Hz. This SMD inductor has a maximum DC current of 300m A with a maximum resistance of 1.1 Ohm. This device utilizes wirewound technology. It has a tolerance of 5%.

安富利:
Ind Chip Wirewound 220nH 5% 100MHz 50Q-Factor Ferrite 300mA 0805 T/R

Chip1Stop:
Inductor Chip Wirewound 220nH 5% 100MHz 50Q-Factor Ferrite 300mA 1.1Ohm DCR 0805 T/R

Verical:
Inductor Chip Wirewound 220nH 5% 100MHz 50Q-Factor Ferrite 300mA 1.1Ohm DCR 0805 T/R

Newark:
# BOURNS  CW201212-R22J  Surface Mount High Frequency Inductor, CW201212 Series, 220 nH, 5%, 0805 [2012 Metric], 860 MHz

MASTER:
Inductor RF Wirewound 0.22uH 5% 100MHz 50Q-Factor Ferrite 0.3A 1.1Ohm DCR 0805 T/R

Online Components:
Inductor Chip Wirewound 220nH 5% 100MHz 50Q-Factor Ferrite 300mA 1.1Ohm DCR 0805 T/R

Electro Sonic:
Inductor RF Wirewound 0.22uH 5% 100MHz 50Q-Factor Ferrite 0.3A 1.1Ohm DCR 0805 T/R
