VISHAY CRCW12062K70JNEAIF 片式电阻器, 表面贴装, 厚膜, AEC-Q200 CRCW系列, 2.7 kohm, 200 V, 1206 [3216公制], 250 mW, ± 5%
The Vishay D/CRCW-IF e3 series Lead Pb-free thick film, rectangular, pulse proof chip resistors. The D/CRCW-IF e3 series resistors have Pure tin plating which provides compatibility with lead Pb-free and lead containing soldering processes.
- .
- High pulse performance
- .
- Metal glaze on high quality ceramic
- .
- Protective overglaze
- .
- Excellent stability ΔR/R
- .
- Lead Pb-free solder contacts on Ni barrier layer
额定电压DC 200 V
额定功率 250 mW
电阻 2.7 kΩ
阻值偏差 ±5 %
额定电压 200 V
安装方式 Surface Mount
引脚数 2
封装公制 3216
封装 1206
长度 3.2 mm
宽度 1.6 mm
封装公制 3216
封装 1206
工作温度 -55℃ ~ 155℃
温度系数 ±200 ppm/K
包装方式 Cut Tape CT
制造应用 消费电子产品, Automotive, Portable Devices, 便携式器材, Industrial, Power Management, 工业, Consumer Electronics, 车用, 电源管理
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC标准 No SVHC
| 型号/品牌 | 代替类型 | 替代型号对比 |
|---|---|---|
CRCW12062K70JNEAIF Vishay Semiconductor 威世 | 当前型号 | 当前型号 |
ERJ8GEYJ272V 松下 | 类似代替 | CRCW12062K70JNEAIF和ERJ8GEYJ272V的区别 |
