Cap Ceramic 0.015uF 6.3V X7R 10% SMD 0402 125℃ T/R
SMD Comm X7R, Ceramic, Commercial Grade, 0.015 uF, 10%, 6.3 VDC, X7R, SMD, MLCC, Temperature Stable, Class II, 0402
立创商城:
15nF ±10% 6.3V
得捷:
CAP CER 0.015UF 6.3V X7R 0402
贸泽:
Multilayer Ceramic Capacitors MLCC - SMD/SMT 6.3volts 15000pF X7R 10%
艾睿:
This C0402C153K9RACTU multilayer ceramic capacitor from Kemet has so many uses that it even has a standard classification system for all its uses! It can withstand a voltage of 6.3 VDC. This MLCC capacitor has a maximum operating temperature of 125 °C. This component will be shipped in tape and reel packaging for effective mounting and safe delivery. This product is 1 mm long, 0.5 mm tall and 0.5 mm deep. Its capacitance value is 0.015uF. It has a tolerance of 10%.
Verical:
Cap Ceramic 0.015uF 6.3V X7R 10% Pad SMD 0402 125C T/R
额定电压DC 6.3 V
绝缘电阻 10 GΩ
电容 0.015 µF
等效串联电阻ESR 55 mΩ
容差 ±10 %
电介质特性 X7R
击穿电压集电极-发射极 45 V
最小电流放大倍数hFE 60 @1mA, 5V
额定功率Max 450 mW
工作温度Max 125 ℃
工作温度Min 55 ℃
额定电压 6.3 V
安装方式 Surface Mount
封装公制 1005
封装 0402
引脚间距 0.3 mm
长度 1 mm
宽度 0.5 mm
高度 0.5 mm
封装公制 1005
封装 0402
引脚间距 0.3 mm
介质材料 Ceramic
工作温度 -55℃ ~ 125℃
产品生命周期 Active
包装方式 Tape & Reel TR
制造应用 通用
RoHS标准 RoHS Compliant
含铅标准
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
C0402C153K9RACTU KEMET Corporation 基美 | 当前型号 | 当前型号 |
C0402C153K5RACTU 基美 | 功能相似 | C0402C153K9RACTU和C0402C153K5RACTU的区别 |
C0402C153K4RACTU 基美 | 功能相似 | C0402C153K9RACTU和C0402C153K4RACTU的区别 |
C0402C153K8RACTU 基美 | 功能相似 | C0402C153K9RACTU和C0402C153K8RACTU的区别 |
