0402 2.2uF ±10% 25V -B
2.2µF ±10% 25V Ceramic Capacitor JB 0402 1005 Metric
得捷:
CAP CER 2.2UF 25V JB 0402
立创商城:
2.2uF ±10% 25V
艾睿:
This C1005JB1E225K050BC multilayer ceramic capacitor from TDK is available with a variety of capacitance values, voltage ratings, package sizes, and other parameters. It can withstand a voltage of 25 VDC. This MLCC capacitor has a maximum operating temperature of 85 °C. This component will be shipped in tape and reel packaging for effective mounting and safe delivery. This product is 1 mm long, 0.5 mm tall and 0.5 mm deep. It has a tolerance of 10%. Its capacitance value is 2.2uF.
额定电压DC 25.0 V
电容 2.2 µF
容差 ±10 %
工作温度Max 85 ℃
工作温度Min -25 ℃
额定电压 25 V
安装方式 Surface Mount
封装公制 1005
封装 0402
长度 1.00 mm
宽度 0.5 mm
高度 0.5 mm
封装公制 1005
封装 0402
厚度 0.5 mm
材质 -B/-25℃~+85℃
介质材料 Ceramic Multilayer
工作温度 -25℃ ~ 85℃
产品生命周期 Active
包装方式 Tape & Reel TR
最小包装 10000
制造应用 Commercial Grade, 通用
RoHS标准 RoHS Compliant
含铅标准 Lead Free
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
C1005JB1E225K050BC TDK 东电化 | 当前型号 | 当前型号 |
C1005JB1E225M050BC 东电化 | 类似代替 | C1005JB1E225K050BC和C1005JB1E225M050BC的区别 |
C1005JB1V225K050BC 东电化 | 功能相似 | C1005JB1E225K050BC和C1005JB1V225K050BC的区别 |
C1005JB1C225K050BC 东电化 | 功能相似 | C1005JB1E225K050BC和C1005JB1C225K050BC的区别 |
