TEXAS INSTRUMENTS CD74HC259MT 芯片, 锁存器, 可寻址, 8位, SOIC-16
Say goodbye to real time information seeping through logic gates by using this d-type low-level latch from Texas Instruments. This latch has a minimum operating temperature of -55 °C and a maximum of 125 °C. This product will be shipped in tape and reel packaging for quick mounting and safe delivery. It has 8 channels per chip. This non-inverting device has a typical operating supply voltage of 2.5|3.3|5 V. Its minimum operating supply voltage of 2 V, while its maximum is 6 V.
电源电压DC 2.00V min
输出接口数 8
输出电流 5.20 mA
电路数 2
针脚数 16
位数 8
极性 Non-Inverting
输入数 1
工作温度Max 125 ℃
工作温度Min -55 ℃
电源电压 2V ~ 6V
电源电压Max 6 V
电源电压Min 2 V
安装方式 Surface Mount
引脚数 16
封装 SOIC-16
封装 SOIC-16
工作温度 -55℃ ~ 125℃
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC标准 No SVHC
REACH SVHC版本 2015/06/15
ECCN代码 EAR99
| 型号/品牌 | 代替类型 | 替代型号对比 |
|---|---|---|
CD74HC259MT TI 德州仪器 | 当前型号 | 当前型号 |
CD74HC259M96E4 德州仪器 | 完全替代 | CD74HC259MT和CD74HC259M96E4的区别 |
CD74HC259M 德州仪器 | 类似代替 | CD74HC259MT和CD74HC259M的区别 |
CD74HC259M96 德州仪器 | 类似代替 | CD74HC259MT和CD74HC259M96的区别 |
