1206 47nF ±20% 630V X7T
0.047 µF ±20% 630V 陶瓷器 X7T 1206（3216 公制）
得捷:
CAP CER 0.047UF 630V X7T 1206
艾睿:
This C3216X7T2J473M160AE multilayer ceramic capacitor from TDK offers high stability and low losses for resonant circuit applications. It can withstand a voltage of 630 VDC. This MLCC capacitor has a maximum operating temperature of 125 °C. This component will be shipped in tape and reel packaging for effective mounting and safe delivery. It has a tolerance of 20%. This device utilizes flexiterm technology. Its capacitance value is 0.047uF. This product is 3.2 mm long, 1.6 mm tall and 1.6 mm deep.
Chip1Stop:
Cap Ceramic 0.047uF 630V X7T 20% SMD 1206 FlexiTerm 125℃ Plastic T/R
Verical:
Cap Ceramic 0.047uF 630V X7T 20% Pad SMD 1206 Soft Termination 125C T/R
额定电压DC 630 V
电容 47 nF
容差 ±20 %
工作温度Max 125 ℃
工作温度Min -55 ℃
额定电压 630 V
安装方式 Surface Mount
封装公制 3216
封装 1206
长度 3.2 mm
宽度 1.6 mm
高度 1.6 mm
封装公制 3216
封装 1206
厚度 1.6 mm
材质 X7T/-55℃~+125℃
工作温度 -55℃ ~ 125℃
产品生命周期 Active
包装方式 Tape & Reel TR
最小包装 2000
制造应用 Boardflex 敏感, for Automotive use., Please refer to Part No., Commercial Grade
RoHS标准 RoHS Compliant
含铅标准 Lead Free
| 型号/品牌 | 代替类型 | 替代型号对比 |
|---|---|---|
C3216X7T2J473M160AE TDK 东电化 | 当前型号 | 当前型号 |
C3216X7T2J473K160AE 东电化 | 类似代替 | C3216X7T2J473M160AE和C3216X7T2J473K160AE的区别 |
C3216X7T2J473M160AC 东电化 | 类似代替 | C3216X7T2J473M160AE和C3216X7T2J473M160AC的区别 |
CGA5L1X7T2J473M160AC 东电化 | 类似代替 | C3216X7T2J473M160AE和CGA5L1X7T2J473M160AC的区别 |
