0805 15nF ±5% 50V NPO
±5% 50V 陶瓷器 C0G,NP0 0805(2012 公制)
得捷:
CAP CER 0.015UF 50V NP0 0805
立创商城:
15nF ±5% 50V
艾睿:
This C2012NP01H153J085AA multilayer ceramic capacitor from TDK offers high stability and low losses for resonant circuit applications. It can withstand a voltage of 50 VDC. This MLCC capacitor has a maximum operating temperature of 150 °C. In order to guarantee safe delivery and allow for quick mounting of this component after delivery, it will be enclosed in tape and reel packaging during shipment. This product is 2 mm long, 0.85 mm tall and 1.25 mm deep. It has a tolerance of 5%. Its capacitance value is 0.015uF.
安富利:
Cap Ceramic 0.015uF 50V C0G 5% SMD 0805 150°C Punched Paper T/R
Verical:
Cap Ceramic 0.015uF 50V C0G 5% Pad SMD 0805 150C T/R
儒卓力:
**KC 15nF 0805 5% 50V NP0 **
额定电压DC 50 V
电容 0.015 µF
容差 ±5 %
工作温度Max 150 ℃
工作温度Min -55 ℃
额定电压 50 V
安装方式 Surface Mount
封装公制 2012
封装 0805
长度 2 mm
宽度 1.25 mm
高度 0.85 mm
封装公制 2012
封装 0805
厚度 0.85 mm
材质 NP0/-55℃~+125℃
工作温度 -55℃ ~ 150℃
产品生命周期 Active
包装方式 Tape & Reel TR
最小包装 4000
制造应用 通用, for Automotive use., Please refer to Part No., Commercial Grade
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ECCN代码 EAR99
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
C2012NP01H153J085AA TDK 东电化 | 当前型号 | 当前型号 |
C2012C0G1H153J085AA 东电化 | 类似代替 | C2012NP01H153J085AA和C2012C0G1H153J085AA的区别 |
C2012C0G1E153J085AA 东电化 | 功能相似 | C2012NP01H153J085AA和C2012C0G1E153J085AA的区别 |
