TDK C4532X7R1H335M200KA 多层陶瓷电容器, 表面贴装, 1812 [4532 公制], 3.3 µF, 50 V, ± 20%, X7R, C Series 新
3.3µF ±20% 50V Ceramic Capacitor X7R 1812 4532 Metric
得捷:
CAP CER 3.3UF 50V X7R 1812
立创商城:
3.3uF ±20% 50V
e络盟:
TDK C4532X7R1H335M200KA 多层陶瓷电容器, 表面贴装, 1812 [4532 公制], 3.3 µF, 50 V, ± 20%, X7R, C Series
艾睿:
Use its standard classification system to find out what this C4532X7R1H335M200KA multilayer ceramic capacitor from TDK can do for you! It can withstand a voltage of 50 VDC. This MLCC capacitor has a maximum operating temperature of 125 °C. In order to guarantee safe delivery and allow for quick mounting of this component after delivery, it will be enclosed in tape and reel packaging during shipment. This product is 4.5 mm long, 2 mm tall and 3.2 mm deep. Its capacitance value is 3.3uF. It has a tolerance of 20%.
安富利:
CAP 3.3UF 50VDC X7R 20% SMD 1812
富昌:
C 系列 1812 3.3 uF 50 V ±20 % 容差 X7R 表面贴装 多层陶瓷 电容
Verical:
Cap Ceramic 3.3uF 50V X7R 20% Pad SMD 1812 125C Low ESR T/R
Newark:
# TDK C4532X7R1H335M200KA SMD Multilayer Ceramic Capacitor, 1812 [4532 Metric], 3.3 µF, 50 V, ± 20%, X7R, C Series
Electro Sonic:
Cap Ceramic 3.3uF 50V X7R 20% SMD 1812 125°C T/R
额定电压DC 50.0 V
电容 3.3 µF
容差 ±20 %
电介质特性 X7R
工作温度Max 125 ℃
工作温度Min -55 ℃
额定电压 50 V
安装方式 Surface Mount
引脚数 2
封装公制 4532
封装 1812
长度 4.50 mm
宽度 3.20 mm
高度 2 mm
封装公制 4532
封装 1812
厚度 2.00 mm
材质 X7R/-55℃~+125℃
介质材料 Ceramic Multilayer
工作温度 -55℃ ~ 125℃
产品生命周期 Production Not Recommended for New Design
包装方式 Cut Tape CT
最小包装 1000
制造应用 通用, Commercial Grade
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC版本 2015/06/15
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
C4532X7R1H335M200KA TDK 东电化 | 当前型号 | 当前型号 |
C4532X7R1H335K200KA 东电化 | 类似代替 | C4532X7R1H335M200KA和C4532X7R1H335K200KA的区别 |
