Switch DIP SP16T 16 Flush Screwdriver 20VAC 20VDC 0.4VA Gull Wing 20000Cycles 2.54mm SMD Tube
Dip Switch Hexadecimal 16 Position Surface Mount Rotary for Tool Actuator 0.4VA 20VAC/DC
得捷:
SWITCH ROTARY DIP HEX 0.40VA 20V
贸泽:
Coded Rotary Switches HEX FLUSH ACT
艾睿:
Switch DIP SP16T 16 Flush Screwdriver 20VAC 20VDC 0.4VA Gull Wing 20000Cycles 2.54mm SMD Tube
Chip1Stop:
Switch DIP SP16T 16 Flush Screwdriver 20VAC 20VDC 0.4VA Gull Wing 20000Cycles 2.54mm SMD Tube
Electro Sonic:
Switch DIP SP16T 16 Flush Screwdriver 20VAC 20VDC 0.4VA Gull Wing 20000Cycles 2.54mm SMD Tube
绝缘电阻 100 MΩ
针脚数 16
接触电阻 50.0 mΩ
工作温度Max 85 ℃
工作温度Min -25 ℃
额定电压 20VAC, 20VDC
额定电压DC Max 20 V
额定电压AC Max 20 V
接触电阻Max 50 mΩ
安装方式 Surface Mount
引脚间距 2.54 mm
长度 8.00 mm
宽度 8.00 mm
高度 4.27 mm
引脚间距 2.54 mm
触点材质 Copper Alloy
工作温度 -25℃ ~ 85℃
产品生命周期 20000 Cycles
包装方式 Tube
RoHS标准 Non-Compliant
含铅标准 Contains Lead
| 型号/品牌 | 代替类型 | 替代型号对比 |
|---|---|---|
CD16RM0SK C&K Components | 当前型号 | 当前型号 |
CD16RM0SB C&K Components | 完全替代 | CD16RM0SK和CD16RM0SB的区别 |
CD16RM0SKR C&K Components | 完全替代 | CD16RM0SK和CD16RM0SKR的区别 |
94HAB16WRT Grayhill | 功能相似 | CD16RM0SK和94HAB16WRT的区别 |
