Yageo 1812 系列高电压 NP0/X7R 系列陶瓷片状电容器,采用无铅端接 应用包括:PC、硬盘、游戏 PC;电源;LCD 面板;ADSL、调制解调器 ### 1812 系列### 注根据电介质、电压及电容分类。
MLCC-多层陶瓷器
得捷:
CAP CER 10000PF 2KV X7R 1812
立创商城:
10nF ±10% 2kV
欧时:
### Yageo 1812 系列高电压 NP0/X7R 系列陶瓷片状电容器,采用无铅端接 应用包括:PC、硬盘、游戏 PC;电源;LCD 面板;ADSL、调制解调器 ### 1812 系列### 注根据电介质、电压及电容分类。
贸泽:
Multilayer Ceramic Capacitors MLCC - SMD/SMT 10nF 2K V X7R 10%
艾睿:
Do you need a capacitor with high stability and low losses? Then this CC1812KKX7RDBB103 multilayer ceramic capacitor from Yageo is the solution you are looking for! It can withstand a voltage of 2000 VDC. This MLCC capacitor has a maximum operating temperature of 125 °C. This component will be shipped in tape and reel packaging for effective mounting and safe delivery. Its capacitance value is 0.01uF. It has a tolerance of 10%. This product is 4.5 mm long, 2 mm tall and 3.2 mm deep.
富昌:
1812 10 nF 2 kV ±10 % Tolerance X7R SMT Multilayer Ceramic Capacitor
Chip1Stop:
Cap Ceramic 0.01uF 2000V X7R 10% SMD 1812 125℃ Blister T/R
Verical:
Cap Ceramic 0.01uF 2000V X7R 10% Pad SMD 1812 125C T/R
Newark:
# YAGEO PHYCOMP CC1812KKX7RDBB103 SMD Multilayer Ceramic Capacitor, 1812 [4532 Metric], 0.01 µF, 2 kV, ± 5%, X7R, CC Series
儒卓力:
**KC 10nF 1812 10% 2000V X7R **
Win Source:
10000pF 2000V 2kV Ceramic Capacitor X7R 1812 4532 Metric 0.177" L x 0.125" W 4.50mm x 3.20mm
额定电压DC 2 kV
电容 10000 pF
容差 ±10 %
电介质特性 X7R
产品系列 HV
工作温度Max 125 ℃
工作温度Min -55 ℃
额定电压 2 kV
安装方式 Surface Mount
引脚数 2
封装公制 4832
封装 1812
长度 4.5 mm
宽度 3.2 mm
高度 2 mm
封装公制 4832
封装 1812
材质 X7R/-55℃~+125℃
工作温度 -55℃ ~ 125℃
温度系数 ±15 %
产品生命周期 Active
包装方式 Tape & Reel TR
最小包装 1000
制造应用 工业, Industrial, 通用, 电源管理, 便携式器材, Consumer Electronics, Power Management, 消费电子产品, Portable Devices
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC标准 No SVHC
REACH SVHC版本 2016/06/20
ECCN代码 EAR99
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
CC1812KKX7RDBB103 Yageo 国巨 | 当前型号 | 当前型号 |
C1812X103KGRACTU 基美 | 类似代替 | CC1812KKX7RDBB103和C1812X103KGRACTU的区别 |
C1812C103KGRACTU 基美 | 功能相似 | CC1812KKX7RDBB103和C1812C103KGRACTU的区别 |
