数字电位计，ON Semiconductor### 数字电位计 - ON Semiconductor
数字电位计，
### 数字电位计 - ON Semiconductor
得捷:
IC DGTL POT 100KOHM 32TAP SC70
立创商城:
CAT5110SDI-00GT3
欧时:
ON Semiconductor CAT5110SDI-00GT3 120kΩ 32位置 线性 数字电位计, 串行 2 线接口, 6引脚 SC-70封装
艾睿:
Ideal for radio frequency processing circuits this CAT5110SDI-00GT3 digital potentiometer from ON Semiconductor belongs in your design. This digital potentiometer has a minimum operating temperature of -40 °C and a maximum of 85 °C. This product will be shipped in tape and reel packaging to allow for quick mounting and safe delivery. This device uses a single power supply.
Allied Electronics:
CAT5110SDI-00GT3, Digi Potentiomtr 120kOhm 32-Pos Linear Serial-2Wire 6-Pin SC-70
容差 ±20 %
无卤素状态 Halogen Free
电路数 1
针脚数 32
电阻 100 kΩ
工作温度Max 85 ℃
工作温度Min -40 ℃
电源电压 2.7V ~ 5.5V
安装方式 Surface Mount
引脚数 6
封装 SOT-363-6
长度 2.2 mm
宽度 1.35 mm
高度 1 mm
封装 SOT-363-6
工作温度 -40℃ ~ 85℃
温度系数 ±200 ppm/℃
产品生命周期 Active
包装方式 Tape & Reel TR
制造应用 Gain adjustment, LCD screen adjustment, Mechanical potentiometer replacement, Line impedance matching, Volume control
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ECCN代码 EAR99
