CAT5119TBI-50GT3

CAT5119: 数字电位计 POT，32 抽头，带 2 线接口

CAT5119 linear-taper digital POT performs the same function as a mechanical potentiometer or a variable resistor. This device consists of a fixed resistor and a wiper contact with 32-tap points that are digitally controlled through a 2-wire up/down serial interface.The CAT5119 is configured as a variable resistor.Three resistance values are available: 10 kΩ, 50 kΩ and 100k Ω.

Features

---

 |

.

0.3 µA Ultra-low standby current

.

Single-supply operation: 2.7 V to 5.5 V

.

Glitchless switching between resistor taps

.

Power-on reset to midscale

.

2-Wire up/down serial interface

.

Resistance values: 10 kΩ, 50 kΩ and 100 kΩ
