1210 2.2uF ±20% 100V X7R
±20% 100V 陶瓷器 X7R 1210（3225 公制）
得捷:
CAP CER 2.2UF 100V X7R 1210
立创商城:
2.2uF ±20% 100V
艾睿:
You can&s;t go wrong with this CGA6N3X7R2A225M230AB multilayer ceramic capacitor from TDK, it is the most commonly used type of capacitor for multiple applications! It can withstand a voltage of 100 VDC. This MLCC capacitor has a maximum operating temperature of 125 °C. Tape and reel packaging will encase this product during shipment, in order to ensure safe delivery and enable quick mounting of components. It has a tolerance of 20%. Its capacitance value is 2.2uF. This product is 3.2 mm long, 2.3 mm tall and 2.5 mm deep.
额定电压DC 100 V
电容 2.2 µF
容差 ±20 %
工作温度Max 125 ℃
工作温度Min -55 ℃
额定电压 100 V
安装方式 Surface Mount
封装公制 3225
封装 1210
长度 3.2 mm
宽度 2.5 mm
高度 2.3 mm
封装公制 3225
封装 1210
厚度 2.3 mm
材质 X7R/-55℃~+125℃
工作温度 -55℃ ~ 125℃
产品生命周期 Active
包装方式 Tape & Reel TR
最小包装 2000
制造应用 汽车级, Automotive Grade
RoHS标准 RoHS Compliant
含铅标准 Lead Free
| 型号/品牌 | 代替类型 | 替代型号对比 |
|---|---|---|
CGA6N3X7R2A225M230AB TDK 东电化 | 当前型号 | 当前型号 |
C3225X7R2A225M230AB 东电化 | 完全替代 | CGA6N3X7R2A225M230AB和C3225X7R2A225M230AB的区别 |
C3225X7R2A225M230AE 东电化 | 完全替代 | CGA6N3X7R2A225M230AB和C3225X7R2A225M230AE的区别 |
C3225X7R2A225M/SOFT 东电化 | 完全替代 | CGA6N3X7R2A225M230AB和C3225X7R2A225M/SOFT的区别 |
