微200毫安低压差稳压器跟踪/线路驱动器 Micropower 200 mA Low Dropout Tracking Regulator/Line Driver
The CS8182 is a monolithic integrated low dropout tracking regulator designed to provide adjustable buffered output voltage that closely tracks ± 10 mV the reference input. The output delivers up to 200 mA while being able to be configured higher, lower or equal to the reference voltage.The output has been designed to operate over a wide range 2.8 V to 45 V while still maintaining excellent DC characteristics. The CS8182 is protected from reverse battery, short circuit and thermal runaway conditions. The device also can withstand 45 V load dump transients and 50 V reverse polarity input voltage transients. This makes it suitable for use in automotive environments. The V/ENABLE lead serves two purposes. It is used to provide the input voltage as a reference for the output and it also can be pulled low to place the device in sleep mode where it nominally draws less than 30 µA from the supply.
Features
---
|
输出接口数 1
输出电压 2.8V ~ 45V
输出电流 200 mA
输入电压Max 45 V
输入电压Min 3.4 V
输出电流Max 0.2 A
工作温度Max 125 ℃
工作温度Min 40 ℃
输入电压 3.4V ~ 45V
安装方式 Surface Mount
引脚数 5
封装 TO-252-5
长度 6.73 mm
宽度 6.22 mm
高度 2.38 mm
封装 TO-252-5
工作温度 -40℃ ~ 125℃
产品生命周期 Unknown
包装方式 Tube
制造应用 Automotive
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ECCN代码 EAR99
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
CS8182DTG ON Semiconductor 安森美 | 当前型号 | 当前型号 |
CS8182DTRKG 安森美 | 类似代替 | CS8182DTG和CS8182DTRKG的区别 |
