TEXAS INSTRUMENTS CD74HC139MT 芯片, 解码器/信号分离器, 双路, 2:4, SOIC16
Safety is important to allow for products to safely fail, implement this from Texas Instruments to decode multiplexed or non-binary data. This decoder has an operating temperature range of -55 °C to 125 °C. This component will be shipped in tape and reel packaging for effective mounting and safe delivery. This inverting device has a typical operating supply voltage of 2.5|3.3|5 V. Its minimum operating supply voltage of 2 V, while its maximum is 6 V.
电源电压DC 2.00V min
输出接口数 4
触点类型 DP4T
针脚数 16
位数 4
带宽 28.0 MHz
输入数 2
工作温度Max 125 ℃
工作温度Min -55 ℃
电源电压 2V ~ 6V
电源电压Max 6 V
电源电压Min 2 V
安装方式 Surface Mount
引脚数 16
封装 SOIC-16
高度 1.5 mm
封装 SOIC-16
工作温度 -55℃ ~ 125℃
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC标准 No SVHC
REACH SVHC版本 2015/06/15
ECCN代码 EAR99
| 型号/品牌 | 代替类型 | 替代型号对比 |
|---|---|---|
CD74HC139MT TI 德州仪器 | 当前型号 | 当前型号 |
CD74HC139M 德州仪器 | 完全替代 | CD74HC139MT和CD74HC139M的区别 |
CD74HC139M96 德州仪器 | 完全替代 | CD74HC139MT和CD74HC139M96的区别 |
74HC139D 恩智浦 | 功能相似 | CD74HC139MT和74HC139D的区别 |
